Aluminum profiles BH 20-6

Aluminum profiles BH 20-6

Aluminum profiles of the BH 20-6 series are miniature profiles, designed primarily for creating very light structures, such as doors, windows and covers of machines and production lines . The basis of the entire series is the 20x20 modular section , from which the multiples of the supplied profiles are derived. The BH 20-6 series of profiles has an identical groove with a width of 6 mm .

₹ 1,000.00 ₹ 1,000.00

  • Size
  • Profile Length

This combination does not exist.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Register

When you register, you will receive a permanent 5% discount on your purchases.


Profile Matching

You can easily add perpendicular profile cuts to your cart.


Technical Documents

Below you can download technical documentation including 3D models.

Conveyor configurator

In our configurator, you can quickly and conveniently create up to 5 types of conveyors.

A small aluminum profile designed primarily for creating windows and doors in machine covers and production lines.

Made of aluminum alloy EN AW 6060 T5, anodizing layer more than 12 microns, tolerances according to EN 12020-2.

Possibility of delivery in large packages - small bundle of 10 bars, large bundle of 150 bars.

Product parameters:

Series :

BH-20-6

Profile section :

20x20

Weight (kg/m) :

0.45

Material :

anodized aluminum

Color :

natural

Profile length (mm) :

6,040

Moment of inertia lx (cm⁴) :

0.67

Moment of inertia ly (cm⁴) :

0.67

Sectional moment wx (cm³) :

0.67

Sectional moment wy (cm³) :

0.67

Cutting area (mm²) :

165


Joining profiles

The choice of fastening between different profiles is very important in any assembly structure. The customer has the opportunity to choose different solutions depending on the required implementation time or the nature of the load or load capacity.

1. Connection using screws in the groove

This is the simplest and fastest way to install. This connection system guarantees good perpendicularity between the two surfaces (depending on the profile section) and good resistance of the connection in the transverse direction to the groove.

2. Connecting using a connecting latch

This assembly is very simple and safe and guarantees a solid connection even when the screws are loosened.

Profile threads

To create a thread, it is recommended to respect the depth specified in the table:

Profile

Screw diameter

Recommended depth (mm)

groove 6

M6

15

groove 8

M8

25

groove 10

M12

30

The maximum tightening torques recommended for screws used in the ALUSIC system are:

Profile

Screw diameter

Max. recommended tightening torque (Nm)

groove 6

M6

10

groove 8

M8

20

groove 10

M12

35

Compatible accessories for all types of panel connections can be found on the related products tab.

 Technical Sheet

 STEP 3D - 084.111.001
